Titanium Alloy Grade9 Ti-3Al-2.5V alloy is an alpha alloy that is strengthened by cold working. The material exhibits good ductility and toughness. It is used in a wide range of tubular products from aircraft ducting to golf club shafts and bicycle frames. The alloy is available as wire, bar, sheet, seamless and welded tubing. ASME code approved.
Standard Specification: ASTM B863, ASME SB863, ASTM F136, ISO, DIN AWS A5.16 (ERTi-23)
Standard |
Werkstoff No. | UNS |
Titanium Alloy Grade9 Ti-3Al-2.5V | 3.7195 | R56320 |
Technical Data Sheet
Chemical Composition |
|||||||||
Weight % | Ti | Al | V | C | Fe | N | O | H | |
Titanium Alloy Grade9 Ti-3Al-2.5V | Balance | 2.5~3.5 | 2.0~3.0 | 0.08 | 0.25 | 0.03 | 0.15 | 0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min | Yield Strength (0.2% Offset) min or range | Elongation in 4D,min% | Reduction of Area
Min % |
||
ksi | MPa | ksi | MPa | |||
Titanium Alloy Grade9 Ti-3Al-2.5V | 90 | 620 | 70 | 483 | 15 | 25 |
