Titanium Alloy Grade 2 is “unalloyed” titanium offering an excellent balance
of strength and ductility. The material has good toughness and is readily
weldable. This material is very corrosion resistant in highly oxidizing and
mildly reducing environments.
Standard: ASMESB338; ASTM B861; ASTM B862;AMS4942;AMS4945;AMS4944;AMS4943; GB/T3625;
Standard |
Werkstoff No. |
UNS |
Commercial Pure Titanium Grade2 |
3.7035 |
R50400 |
Technical Data Sheet
Chemical Composition |
||||||
Weight % |
Ti |
C |
Fe |
N |
O |
H |
Commercial Pure Titanium Grade2 |
Balance |
0.08 |
0.3 |
0.03 |
0.25 |
0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area Min % |
||
ksi |
MPa |
ksi |
MPa |
|||
Commercial Pure Titanium Grade2 |
50 |
345 |
40 |
275 |
20 |
30 |
