Titanium Alloy Grade 12 is lightly alloyed near-alpha alloy offering improved strength at elevated temperatures and optimum ASME Code design allowables. The material is readily weldable, and has superior crevice corrosion resistance. This material is very corrosion resistant in highly oxidizing and mildly reducing environments.
Standard Specification: ASTM B338 ASTM B861, ASTM B862 GB/T3625
Standard |
Werkstoff No. |
UNS |
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
3.7105 |
R53400 |
Technical Data Sheet
Chemical Composition |
|||||||||
Weight % |
Ti |
Mo |
Ni |
C |
Fe |
N |
O |
H |
|
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
Balance |
0.2~0.4 |
0.6~0.9 |
0.08 |
0.3 |
0.03 |
0.25 |
0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area Min % |
||
ksi |
MPa |
ksi |
MPa |
|||
Titanium Alloy Grade 12 Ti-0.3Mo-0.8Ni |
70 |
483 |
50 |
345 |
18 |
25 |
